Non-Mechanical
WB – Ice Chest
The WB Series ice chests make it possible to put large capacity ice storage directly in your serving line. The convenience of a removable hinged lid is included. Maximize your efficiency—put ice service where you need it most.
The ice chest is fully insulated and provided with a factory-applied gasket so that it can be installed in the finest wood fixtures without marring the countertop. The unit is constructed of stainless steel and is provided with a 1″ IPS drain.
Features
- Fully insulated to hold ice longer
- Removable S/S hinged lid
- Factory-applied gasket makes installation a snap and seals units to the countertop, thus eliminating seepage
- 1-Year Parts & Labor Warranty
Top
- Constructed of 18-gauge, type 304 stainless steel, die stamped with a raised perimeter bead.
- There shall be a solid vinyl gasket under the beaded edge to form a seal with the countertop, thus preventing seepage or marring of the countertop.
Ice Chest
- The inner liner shall be 22-gauge, type 304 stainless steel.
- All corners are coved with a minimum 1/4″ radius.
- A 1″ diameter threaded drain fitting is provided.
Insulation
- The pan is fully insulated with high density polystyrene, 1″ thick on all sides, 1-1/2″ thick on the bottom and enclosed with a 24-gauge galvanized steel outer liner.
Lid
- The ice chest is provided with a stainless steel double pan, insulated lid with a rubber, self-insulating hinge.
- The entire lid is removable.
Models
- WB-15
- WB-19
