Non-Mechanical
BL-CU – Corner Units
Eliminates wasted space. Creates usable customer serving areas—keeps the line flowing and provides an opportunity for more food display—higher sales.
A wide range of attractive plastic laminate colors is available, or urethane painted panels to blend with any decor.
Quality construction provides years of reliable service. Complete reliability—use as an individual unit or joined in a continuous serving line with our exclusive CAM LOCK™ system.
Features
- Attractive plastic laminate panels
- Stainless steel tray slide (non-folding on BL-CU-O only)
- Economical cost
- CAM LOCK™ system
Top
Constructed of 16 gauge, type 304 stainless steel, die-formed, welded, ground and polished to a uniform finish with rolled front edge.
Body
- Frame construction shall be of hi-tensile square aluminum tubing, 1-1/4”, with 3-3/4” extruded, vertical radius corners.
- Frame sections are welded construction, ground and polished to a uniform finish.
- Body is complete with front panel, end panels and 8-5/8″ rear apron of plastic laminate on .050 aluminum.
- Owner to specify laminate finish.
- CAM LOCK™ locking system included with each unit to align and retain cart positioning, when two or more units are joined.
Tray Slide
- Constructed of 16 gauge, type 304 stainless steel, welded, ground and polished, with die-formed raised ribs for ease of sliding trays.
- The tray slide has welded corners and reinforced sections where necessary, and is NON-FOLDING (BL-CU-O only).
Casters
- NSF approved, 5″ diameter non-marking rubber tired, swivel plate caster with grease fittings.
- Both casters on the operator’s side have foot-activated breaks.
Models
- BL-CU-I
- BL-CU-O
